Project Description
HOWO water fire truck，water fire fighting truck，fire truck
HOWO Water Foam Fire Truck12000L
HOWO TianJin Fire truck Engine ,Water Tank can be 12000L , if choose Foam tank ,the Foam Tank can do 2000L to 10000L
HOWO Fire Truck water foam tank fire truck 6X4 12000L
JDFtruck is the Chinese fire fighting truck manufacturer , DongFeng fire truck quality have beed approved by CCC and ISO9001:2000 quality certificate ,Contact us: jndfa@hotmail.com.
Our HOWO Fire Truck6500L,Water Fire Truck , Fire Fighting Truck have a wide range of chassis brand optional , different load volume to choose .
| Vehicle Name: | DongFeng Water Foam Fire Truck | Vehicle Category: | HOWO Fire Truck | ||
| Chinese Brand: | HOWO JDFTRUCK | English brand : | HOWO JDFTRUCK | ||
| Notice batch : | 207 | Exemption: | No | ||
| Engine | Engine Manufacturer | Displacement (ml) | Power (kw) | ||
| WD615.92 | China national heavy duty truck group co., LTD | 9726 | 196 | ||
| Engine brand : | DongFeng | Fuel type: | Diesel (mm) | ||
| Dimensions: | 10025X2500X3600(mm) | Compartment Size : | × × (mm) | ||
| The total mass : | 27600(Kg) | Payload: | 0 | ||
| Curb weight: | 14800(Kg) | Rated Quality: | 12350(Kg) | ||
| Quality Trailer : | (kg) | Semitrailer saddle : | |||
| Rated capacity : | ( People ) | Cab seats : | 2+4( People ) | ||
| Approach / departure angle : | 16/13(°) | Front / rear overhang : | 1500/2490(mm) | ||
| Axle load: | 6900/2490 | Wheelbase: | 4600+1350,4575+1400(mm) | ||
| Number of axes: | 2 | Maximum speed: | 85(km/h) | ||
| Fuel consumption: | Spring: | 10/12,4/12,10/- | |||
| Number of tires : | 6 | Tire Size: | 11.00-20 18PR,12.00-20 16PR | ||
| Front track: | Rear track: | ||||
| Brake Front: | 1939,1958 | After braking : | 1800/1800,1830/1830 | ||
| Built before the parade : | After operating system : | ||||
| Steering Type : | Steering wheel | Starting method: | |||
| Chassis Emission standard: | GB3847-2005, GB17691-2005 National | ||||
| Transmission Type: | According to the standard : | ||||
| Vin Vehicle Identification Number: | LZZ5BLMFXXXXXXXXX | ||||
| Logo Enterprises : | JDFtruck | Release date: | 20160916 | ||
| Vehicle Notes : | HOWO water fire truck，water fire fighting truck，fire truck. After stretch: 50 mm; Total volume of 6.77 cubic meters of tank; Tank liquid loads for 5000 kg; Tank volume: 5.0 cubic meters; Tank size (length x width x height) : 2535 * 1500 * 1500 (mm); Class B foam tank liquid loads for 2000 kg; Tank volume: 1.77 cubic meters; Tank size (length x width x height) : 897 * 1500 * 1500 (mm) | ||||
HOWO Fire Truck, Fire Truck 12000L, Fire Fighting Truck Chassis
HOWO water fire truck，water fire fighting truck，fire truck
| HOWO truck chassis | HOWO truck chassisZZ1257M4647C | ||||
| Company Name : | China national heavy duty truck group co., LTD | |||
| Chassis Type: | ZZ1257M4647C | Chassis Category: | II | |
| Product Name: | Truck chassis | Product Brand: | HOWO | |
| Zip Code: | Catalog number : | 3 | ||
| Fuel Type: | Diesel fuel | According to the standard : | GB3847-2005(Ⅳ),GB17691-2005 | |
| Steering Type : | Steering wheel | |||
| Number of axes: | 2 | Wheelbase: | 4325+1350,4600+1350 | |
| Spring: | 9/12,10/12,10/- | Number of tires : | 10 | |
| Tire Size: | 11.00-20 18PR,12.00-20 16PR | Tread : | Front track1939,1958Rear track1800/1800,1830/1830 | |
| The total mass : | 28550 | |||
| Curb weight: | 13,100 | Quality Trailer : | 15000 | |
| Semitrailer saddle : | Front passenger : | 3 | ||
| Close to the departure angle: | 16/13 | Rear suspension : | 1500/2490 | |
| Maximum speed: | 85,90 | |||
| Picture: | ||||
