Project Description
dongfeng water fire truck，water fire fighting truck，fire truck
DongFeng 140Water Foam Fire Truck3500L
DongFeng DuoLiKa Fire truck Engine ,Water Tank can be 3500L , if choose Foam tank ,the Foam Tank can do 500L to 2200L
DongFeng Fire Truck water foam tank fire truck 4X2 3500L
JDFtruck is the Chinese fire fighting truck manufacturer , DongFeng fire truck quality have beed approved by CCC and ISO9001:2000 quality certificate ,Contact us: jndfa@hotmail.com.
Our DongFeng Fire Truck3500L,Water Fire Truck , Fire Fighting Truck have a wide range of chassis brand optional , different load volume to choose .
| Vehicle Name: | DongFeng Water Foam Fire Truck | Vehicle Category: | Dong Feng Fire Truck | ||
| Chinese Brand: | Dong Feng JDFTRUCK | English brand : | Dong FengJDFTRUCK | ||
| Engine | Engine Manufacturer | Displacement (ml) | Power (kw) | ||
| 4JB1CN | Dongfeng motor co., LTD | 4260 | 105 | ||
| Engine brand : | DongFeng | Fuel type: | Diesel (mm) | ||
| Dimensions: | 7190×2420×3030(mm) | Compartment Size : | × × (mm) | ||
| The total mass : | 9460(Kg) | Payload: | 0 | ||
| Curb weight: | 5500(Kg) | Rated Quality: | 3510(Kg) | ||
| Rated capacity : | ( People ) | Cab seats : | 2+4( People ) | ||
| Approach / departure angle : | 34/14(°) | Front / rear overhang : | 1065/1920(mm) | ||
| Logo Enterprises : | JDFtruck | Release date: | 20160916 | ||
| Vehicle Notes : | Tank volume: 3.51 cubic meters, water tank size: 2280 * 1320 * 1320 mm, with YC4E140-31 type engine, only after stretch: 255 mm | ||||
DongFeng Water Fire Truck ,Water Fire Truck ,Water Fire Truck Chassis
| Dong Feng truck chassis | Dong Feng truck chassis EQ1092F19DJ5 | ||||
| Company Name : | Dongfeng motor co., LTD | |||
| Chassis Type: | EQ1092F19DJ5 | Chassis Category: | II | |
| Product Name: | Truck chassis | Product Brand: | Dong Feng | |
| Fuel Type: | Diesel fuel | According to the standard : | GB3847-2005(Ⅳ),GB17691-2005 | |
| Number of axes: | 2 | Wheelbase: | 3950 | |
| Spring: | 9/11+8,8/11+8 | Number of tires : | 6 | |
| The total mass : | 9460 | |||
| Curb weight: | 5500 | Quality Trailer : | 3510 | |
dongfeng water fire truck，water fire fighting truck，fire truck
| Dong Feng fire truck chassis | DongFeng fire truck chassis EQ1092F19DJ5 Engine Specification | |||
| Engine Model | Engine Manufacturer | Displacement (ML) | Power (ML) |
| Dongfeng | guangxi yuchai machinery co., LTD
guangxi yuchai machinery co., LTD guangxi yuchai machinery co., LTD guangxi yuchai machinery co., LTD Dongfeng motor co., LTD, commercial vehicle engine plant |
4260
4260 4260 6494 4752 |
105
103 105 118 103 |
